ASUS H81-GAMER
2-29
2.6.2 PCH Conguration
PCI Express Conguration
PCI-E Speed [Auto]
Allows you to select the PCI Express port speed. Conguration options: [Auto] [Gen1]
[Gen2]
Intel
®
Rapid Start Technology
Intel
®
Rapid Start Technology [Disabled]
Allows you to enable or disable Intel
®
Rapid Start Technology. Conguration options:
[Enabled] [Disabled]
The following items appear only when you set the Intel
®
Rapid Start Technology to
[Enabled].
Entry on S3 RTC Wake [Enabled]
The system automatically wakes up and set to Rapid Start Technology S4 mode.
Conguration options: [Enabled] [Disabled]
Entry After [0]
Allows you to set the wake-up time.The values range from 0 (immediately) to 120.
Active Page Threshold Support [Enabled]
The system automatically set itself to sleep when the partition size is not enough for
Rapid Start Technology to work. Conguration options: [Enabled] [Disabled]
Active Memory Threshold [0]
Key in the value for the additional partition size for Rapid Start Technology to work.
Ensure that the caching partition size is larger than the total memory size.
Hybrid Hard Disk Support [Disabled]
Allows you to enable or disable hybrid hard disk support.
Conguration options: [Enabled] [Disabled]
Intel
®
Smart Connect Technology [Disabled]
Intel
®
Smart Connect Technology Support [Disabled]
Allows you to enable or disable the ISCT conguration. Conguration options:
[Enabled] [Disabled]
2.6.3 PCH Storage Conguration
While entering Setup, the BIOS automatically detects the presence of SATA devices. The
SATA Port items show Not Present if no SATA device is installed to the corresponding SATA
port.
