ASUS H81-GAMER
1-9
1.4.3 Installing a DIMM
UnplugthepowersupplybeforeaddingorremovingDIMMsorothersystemcomponents.
Failuretodosocancauseseveredamagetoboththemotherboardandthecomponents.
1. Press the retaining clip outward to
unlockaDIMMsocket.
2. AlignaDIMMonthesocketsuch
thatthenotchontheDIMMmatches
theDIMMslotkeyonthesocket.
ADIMMiskeyedwithanotchsothatittsinonlyonedirection.DONOTforceaDIMM
intoasocketinthewrongdirectiontoavoiddamagingtheDIMM.
3. FirmlyinserttheDIMMintothesocket
until the retaining clip clicks back in
placeandtheDIMMisproperlyseated.
1.4.4 Removing a DIMM
To remove a DIMM:
1. PresstheretainingclipsoutwardtounlocktheDIMM.
2. RemovetheDIMMfromthesocket.
SupporttheDIMMlightlywith
yourngerswhenpressingthe
retainingclip.TheDIMMmight
getdamagedwhenitipsout
with extra force.
DIMM notch
DIMM slot key
