Asus h81-gamer [68/80] Anti surge support enabled
![Asus h81-gamer [68/80] Anti surge support enabled](/views2/1161714/page68/bg44.png)
2-38
Chapter 2: Getting started
Chassis Fan 1 / Chassis Fan 2 Speed Low Limit [300 RPM]
This item appears only when you enable the Chassis Fan1/2 Q-Fan Control feature and
allows you to disable or set the chassis fan warning speed.
Conguration options: [Ignore] [200RPM] [300 RPM] [400 RPM] [500 RPM] [600 RPM]
Chassis Fan 1 / Chassis Fan 2 Prole [Standard]
This item appears only when you enable the Chassis Fan 1/2 Q-Fan Control feature and
allows you to set the appropriate performance level of the chassis fan 1/2.
[Standard] Sets to [Standard] to make the chassis fan automatically adjust depending
on the chassis temperature.
[Silent] Sets to [Silent] to minimize the fan speed for quiet chassis fan operation.
[Turbo] Sets to [Turbo] to achieve maximum chassis fan speed.
[Manual] Sets to [Manual] to assign detailed fan speed control parameters.
The following four items appear only when you set Chassis1/2 Fan Prole to [Manual].
Chassis Fan 1/2 Upper Temperature [70]
Use the <+> and <-> keys to adjust the upper limit of the Chassis temperature. The
values range from 40°C to 75°C.
Chassis Fan 1/2 Max. Duty Cycle(%) [100]
Use the <+> and <-> keys to adjust the maximum chassis fan 1/2 duty cycle. The
values range from 60% to 100%. When the chassis temperature reaches the upper
limit, the chassis fan1/2 will operate at the maximum duty cycle.
Chassis Fan 1/2 Middle Temperature [45ºC]
Use the <+> or <-> keys to adjust the chassis Fan1/2 middle temperature. The values
range from 40ºC to 75ºC.
Chassis Fan 1/2 Middle. Duty Cycle (%) [60]
Use the <+> or <-> keys to adjust the middle chassis fan1/2 duty cycle. The values
range from 60% to 100%. When the chassis temperature reaches the upper limit, the
chassis fan1/2 will operate at the maximum duty cycle.
Chassis Fan 1/2 Lower Temperature [40]
Displays the lower limit of the chassis temperature.
Chassis Fan 1/2 Min. Duty Cycle(%) [60]
Use the <+> and <-> keys to adjust the minimum chassis1/2 fan duty cycle. The values
range from 60% to 100%. When the chassis temperature is under 40°C, the chassis
fan1/2 will operate at the minimum duty cycle.
2.7.7 Anti Surge Support [Enabled]
This item allows you to enable or disable the Anti Surge function.
Conguration options: [Disabled] [Enabled]
