vii
H81-GAMER specications summary
(continued on the next page)
Storage
Intel
®
H81 Express Chipset:
- 2 x Serial ATA 6.0 Gb/s connectors (gray)
- 2 x Serial ATA 3.0 Gb/s connectors (black)
- Supports Intel
®
Rapid Start Technology* and Intel
®
Smart Connect
Technology**
* Due to the limitation of the Intel
®
H81 chipset, Intel
®
Rapid Start Technology can be
congured only from the BIOS Setup program.
** These functions work depending on the CPU installed.
Audio
SupremeFX 8-channel High Denition Audio CODEC
- Supports jack-detection, multi-streaming and front panel MIC jack-retasking
- High quality 115dB SNR stereo playback output
Audio Features:
- SupremeFX Shielding
TM
Technology
- ELNA premium audio capacitors
- Headphone AMP
- Optical S/PDIF out port at back panel
USB
Intel
®
H81 Express Chipset - support ASUS USB 3.0 Boost
- 2 x USB 3.0/2.0 ports at back panel (blue)
Intel
®
H81 Express Chipset
- 8 x USB 2.0/1.1 ports (4 ports at mid-board, 4 ports at rear panel)
ASMedia ASM1042 USB 3.0 Controller
- 2 x USB 3.0 ports at mid-board
ASUS
Gaming
Features
Gamer's Guardian
- ESD Guards on D-Sub, LAN, Audio, KBMS and USB3.0/2.0 ports
- DRAM Overcurrent Protection
- 10K Black Metallic Capacitors
- Stainless Steel Back I/O
- ASUS DIGI+ VRM
Performance Optimization
- ASUS DIGI+ VRM: Digital Power Design for the CPU
- ASUS EPU
- ASUS GPU Boost
- ASUS Fan Xpert 2
- USB 3.0 Boost
EZ DIY
- Push Notice
- UEFI BIOS with EZ Mode / CrashFree BIOS 3 / EZ Flash 2
- Q-Design with ASUS Q-Shield / Q-DIMM / Q-slot
ASUS Exclusive Features
- AI Suite 3
- Disk Unlocker
- AI Charger+
