H81-GAMER specications summary
(continued on the next page)
Package contents
Check your motherboard package for the following items.
Motherboard
ASUS Gaming Motherboard – H81-GAMER
Cables 2 x Serial ATA 6.0 Gb/s cables
Accessories 1 x I/O Shield
Application DVD Support DVD
Documentation User Guide
If any of the above items is damaged or missing, contact your retailer.
CPU
LGA1150 socket for Intel
®
4th, New 4th & 5th Generation Core™ i7 / i5 / i3,
Pentium
®
, and Celeron
®
processors
Supports Intel
®
22nm CPU
Supports Intel
®
Turbo Boost Technology 2.0*
* The Intel
®
Turbo Boost Technology 2.0 support depends on the type of CPU installed
in your system.
** Refer to www.asus.com for Intel
®
CPU support list.
Chipset Intel
®
H81 Express Chipset
Memory
4 x DIMM, maximum 32 GB, DDR3 1600 / 1333 / 1066 MHz, non-ECC, un-buffered
memory*
Dual-channel memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)
* Hyper DIMM support is subject to the physical characteristics of individual CPUs.
Please refer to Memory QVL (Qualied Vendors List) for details.
** Refer to www.asus.com for the latest Memory QVL (Qualied Vendors List).
*** Due to Intel
®
chipset limitation, DDR3 1600 MHz and higher memory modules on XMP
mode will run at the maximum transfer rate of DDR3 1600 MHz.
**** Due to Intel
®
chipset limitation, this motherboard can only support single-sided
memories when four modules are installed and they will run at the maximum transfer
rate of DDR3 1066MHz.
Graphics
Multi-VGA output support: DVI / RGB ports
- Supports DVI with maximum resolution of 1920 x 1200 @ 60 Hz
- Supports RGB with maximum resolution of 1920 x 1200 @ 60 Hz
Supports Intel
®
InTru
TM
3D, Quick Sync Video, Intel
®
Clear Video HD Technology,
and Intel
®
Insider
TM
Maximum shared memory of 512 MB
Expansion
slots
1 x PCI Express 2.0 x16 slot
3 x PCI Express 2.0 x1 slots
3 x PCI slots
LAN Intel
®
Gigabit LAN
