viii
H81-GAMER specications summary
Specications are subject to change without notice.
Rear Panel I/O
ports
1 x PS/2 keyboard port
1 x PS/2 mouse port
1 x Optical S/PDIF out port
1 x DVI port
1 x D-Sub port
2 x USB 3.0 ports
4 x USB 2.0 ports
1 x LAN (RJ45) port
8-channel audio I/O ports
Internal I/O
connectors
1 x 19-pin USB 3.0/2.0 connector supports additional 2 USB 3.0/2.0 ports
2 x USB 2.0/1.1 connectors support additional 4 USB 2.0/1.1 ports
2 x SATA 6.0 Gb/s connectors (gray)
2 x SATA 3.0 Gb/s connectors (black)
1 x CPU Fan connector (4-pin)
2 x Chassis Fan connectors (4-pin)
1 x COM connector
1 x TPM connector
1 x 24-pin EATX Power connector
1 x 8-pin ATX 12V Power connector
1 x Front panel audio connector (AAFP)
1 x System panel
1 x Clear CMOS jumper
BIOS features
64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI2.7, WfM2.0, SM BIOS 2.8,
ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS 3,
F11 EZ Tuning Wizard, F6 Q-Fan Control, F3 My Favorites, Quick Note, Last
Modied log, F12 PrintScreen Function, F3 Shortcut function and ASUS DRAM
SPD(Serial Presence Detect)
Manageability Wfm 2.0, DMI 2.7, WOL by PME, PXE
Support DVD
Drivers
ASUS utilities
EZ Update
Anti-virus software (OEM version)
Form factor ATX form factor: 12.0 in. x 8.4 in. (30.5 cm x 21.4 cm)
