ASUS H81-GAMER
2-31
CPU Graphics Multi-Monitor [Disabled]
Allows you to enable the CPU Graphics Multi-Monitor. For LucidLogix Virtu MVP
function support, set this item to [Enabled] to empower both integrated and discrete
graphics. The CPU Graphics shared system memory size will be xed at 64MB.
Conguration options: [Disabled] [Enabled]
DMI Conguration
Allows you to control various DMI functions.
DMI Gen 2 [Auto]
Allows you to enable or disable DMI Gen 2. Conguration options: [Auto] [Enabled]
[Disabled]
NB PCI-E Conguration
Allows you to congure the NB PCI Express settings.
PCI-EX16_1 Link Speed [Auto]
Allows you to congure the PCIEX16 speed.
Conguration options: [Auto] [Gen1] [Gen2]
Memory Conguration
Memory Scrambler [Enabled]
Allows you to enable or disable Memory Scrambler support.
Memory Remap [Enabled]
Allows you to enable or disable remapping the memory above 4GB.
[Enabled] Enables the function.
[Disabled] Disables this function.
2.6.5 USB Conguration
The items in this menu allow you to change the USB-related features.
The USB Devices item shows the auto-detected values. If no USB device is detected, the
item shows None.
Legacy USB Support [Enabled]
[Enabled] Enables the support for USB devices on legacy operating systems (OS).
[Disabled] The USB devices can be used only for the BIOS setup program.
[Auto] Allows the system to detect the presence of USB devices at startup. If
detected, the USB controller legacy mode is enabled. If no USB device is
detected, the legacy USB support is disabled.
