2-44
Chapter 2: Getting started
Delete the dbx
Allows you to delete the DBX le from your system. Conguration options:
[Yes] [No]
Load Default dbx
Allows you to load the downloaded DBX from a USB storage device.
Append Default dbx
Allows you to load the additional DBX from a storage device so that more
db’s images cannot be loaded.
The DBX le must be formatted as a UEFI variable structure with time-based authenticated
variable.
2.8.11 Boot Option Priorities
These items specify the boot device priority sequence from the available devices. The
number of device items that appears on the screen depends on the number of devices
installed in the system.
• To select the boot device during system startup, press <F8> when ASUS Logo
appears.
• To access Windows OS in Safe Mode, do any of the following:
- Press <F5> when ASUS Logo appears.
- Press <F8> after POST.
2.8.12 Hard Drive BBS Priorities
Allows you to set the order of the legacy devices in this group.
2.8.13 Boot Override
These items displays the available devices. The number of device items that appear on
the screen depends on the number of devices installed in the system. Click an item to start
booting from the selected device.
