ASUS H81-GAMER
1-19
9. Intel
®
H81 Serial ATA 3.0 Gb/s connectors (7-pin SATA3G_1, SATA3G_2 [black])
TheseconnectorsconnecttoSerialATA3.0Gb/sharddiskdrivesandopticaldrivesvia
SerialATA3.0Gb/ssignalcables.
Whenusinghot-plugandNCQ,settheSATA Mode SelectionitemintheBIOSto[AHCI].
SeesectionPCHStorageConguration for details.
SATA3G_2
GND
RSATA_TXP2
RSATA_TXN2
GND
RSATA_RXN2
RSATA_RXP2
GND
SATA3G_1
GND
RSATA_TXP1
RSATA_TXN1
GND
RSATA_RXN1
RSATA_RXP1
GND
H81-GAMER
H81-GAMER Intel
®
SATA 6.0Gb/s connectors
