1-14
Chapter 1: Product Introduction
Chapter 1
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip
NO.
Timing Voltage
DIMM
socket
support
(Optional)
2 4
ADATA AX4U3400W4G16-DWZ 8GB (2 x 4GB) SS - - 16-17-17-36 1.35V •
ADATA AX4U3400W4G16-QWZ 16GB (4 x 4GB) SS - - 16-17-17-36 1.35V • •
CORSAIR CMK16GX4M4B3400C16 16GB (4 x 4GB) SS - - 16-18-18-40 1.35V • •
G.SKILL F4-3400C16Q-16GRKD 16GB (4 x 4GB) SS - - 16-16-16-36 1.35V • •
G.SKILL F4-3400C16Q-16GRBD 16GB (4 x 4GB) SS - - 16-18-18-38 1.35V • •
G.SKILL F4-3400C16D-16GRK 16GB (2 x 8GB) DS - - 16-18-18-38 1.35V •
G.SKILL F4-3400C16D-16GVK 16GB (2 x 8GB) DS - - 16-18-18-38 1.35V •
G.SKILL F4-3400C16D-16GTZ 16GB (2 x 8GB) DS - - 16-18-18-38 1.35V •
G.SKILL F4-3400C16Q-32GRK 32GB (4 x 8GB) DS - - 16-18-18-38 1.35V • •
G.SKILL F4-3400C16Q-32GVK 32GB (4 x 8GB) DS - - 16-18-18-38 1.35V • •
G.SKILL F4-3400C16Q-32GTZ 32GB (4 x 8GB) DS - - 16-18-18-38 1.35V • •
G.SKILL F4-3400C16D-32GRK 32GB (2 x
16GB)
DS - - 16-18-18-38 1.35V •
G.SKILL F4-3400C16D-32GVK 32GB (2 x16GB) DS - - 16-18-18-38 1.35V •
G.SKILL F4-3400C16D-32GTZ 32GB (2 x
16GB)
DS - - 16-18-18-38 1.35V •
G.SKILL F4-3400C16Q-64GRK 64GB (4 x
16GB)
DS - - 16-18-18-38 1.35V • •
G.SKILL F4-3400C16Q-64GVK 64GB (4 x
16GB)
DS - - 16-18-18-38 1.35V • •
G.SKILL F4-3400C16Q-64GTZ 64GB (4 x
16GB)
DS - - 16-18-18-38 1.35V • •
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip
NO.
Timing Voltage
DIMM
socket
support
(Optional)
2 4
ADATA AX4U3333W4G16-DRZ 8GB (2 x 4GB) SS - - 16-16-16-36 1.35V •
ADATA AX4U3333W4G16-QRZ 16GB (4 x 4GB) SS - - 16-16-16-36 1.35V • •
AVEXIR AVDUZ33331604G-
2CIR/BZ1
8GB (2 x 4GB) SS - - 16-18-18-38 1.35V •
AVEXIR AVDUZ33331604G-
4CIR/BZ1
16GB (4 x 4GB) SS - - 16-18-18-38 1.35V • •
CORSAIR CMD16GX4M4B3333C16 16GB (4 x 4GB) SS - - 16-18-18-36 1.35V • •
G.SKILL F4-3333C16Q-16GRRD 16GB (4 x 4GB) SS - - 16-18-18-38 1.35V • •
DDR4 3400 (OC) MHz capability
DDR4 3333 (OC) MHz capability
