Asus rog maximus viii extreme [40/226] Expansion slots

1-22

Chapter 1: Product Introduction

Chapter 1

1.2.5 Expansion slots

Unplug the power cord before adding or removing expansion cards. Failure to do so may

cause you physical injury and damage motherboard components.

Slot No. Slot Description

1 PCIe 3.0 x16/x8_1 slot

2 PCIe 3.0 x4_2 slot

3 PCIe 3.0 x1_1 slot

4 PCIe 3.0 x8/x4_3 slot

5 PCIe 3.0 x1_2 slot

6 PCIe 3.0 x4_4 slot
