Инструкция по эксплуатации Страница: 28

Asus rog maximus viii extreme [28/226] System memory

1-10

Chapter 1: Product Introduction

Chapter 1

Recommended memory configurations

1.2.4 System memory

The motherboard comes with four (4) Double Data Rate 4 (DDR4) Dual Inline Memory

Modules (DIMM) slots.

A DDR4 module is notched differently from a DDR, DDR2, or DDR3 module. DO NOT

install a DDR, DDR2, or DDR3 memory module to the DDR4 slot.
