Asus rog maximus viii extreme [71/226] To install the cpu heatsink and fan assembly

ASUS MAXIMUS VIII EXTREME

2-5

Chapter 2

2.1.3 CPU heatsink and fan assembly installation

Apply the Thermal Interface Material to the

CPU heatsink and CPU before you install

the heatsink and fan, if necessary.

To install the CPU heatsink and fan assembly
