1-12
Chapter 1: Product Introduction
Chapter 1
MAXIMUS VIII EXTREME Motherboard Qualified Vendors Lists (QVL)
DDR4 3733 (OC) MHz capability
DDR4 3800 (OC) MHz capability
DDR4 3700 (OC) MHz capability
Vendors Part No. Size SS/DS
Chip
Brand
Chip
NO.
Timing Voltage
DIMM
socket
support
(Optional)
2 4
ADATA AX4U3700W4G17-DWZ 8GB (2 x 4GB) SS - - 17-18-18-38 1.35V •
ADATA AX4U3700W4G17-QWZ 16GB (4 x 4GB) SS - - 17-18-18-38 1.35V • •
Vendors Part No. Size SS/DS
Chip
Brand
Chip
NO.
Timing Voltage
DIMM
socket
support
(Optional)
2 4
AVEXIR AVD4UZ138001804G-2CIR 8GB (2 x 4GB) SS - - 18-20-20-40 1.35V •
AVEXIR AVD4UZ138001804G-2BZ1 8GB (2 x 4GB) SS - - 18-20-20-40 1.35V •
G.SKILL F4-3800C18D-8GTZ 8GB (2 x 4GB) SS - - 18-20-20-38 1.35V •
Vendors Part No. Size SS/DS
Chip
Brand
Chip
NO.
Timing Voltage
DIMM
socket
support
(Optional)
2 4
ADATA AX4U3733W4G17-DWZ 8GB (2 x 4GB) SS - - 17-18-18-38 1.35V •
AVEXIR AVD4UZ137331804G-
2CIR/BZ1
8GB (2 x 4GB) SS - - 18-20-20-40 1.35V •
AVEXIR AVD4UZ137331804G-
4CIR/BZ1
16GB (4 x 4GB) SS - - 18-20-20-40 1.35V • •
G.SKILL F4-3733C17D-8GVK 8GB (2 x 4GB) SS - - 17-19-19-39 1.35V •
G.SKILL F4-3733C17D-8GTZ 8GB (2 x 4GB) SS - - 17-19-19-39 1.35V •
G.SKILL F4-3733C17Q-8GVK 16GB (4 x 4GB) SS - - 17-19-19-39 1.35V • •
G.SKILL F4-3733C17Q-8GTZ 16GB (4 x 4GB) SS - - 17-19-19-39 1.35V • •
