ASUS MAXIMUS VIII EXTREME
4-31
Chapter 4
Remote Keyboard & Mouse
RemoteKeyboard&Mouseallowsyoutouseyoursmartdevice’stouchpanelasaremote
keyboardandmouseforyourcomputer.
Input field
Control keys
Tap to switch between zoom
and magnifier function
Tap to switch between
running tasks and apps
Tap to display the
Start menu
Mouse tap area
Tap to mimic right-
click mouse function
Tap to mimic left-
click function
Slide up/down to scroll
ASUS Media Streamer
TheASUSMediaStreamerallowsyoutoenjoyyourPC’smultimediacontentanywhere.You
canpipemusicfromyourPCorstreamyourfavoritemovietoasmartTVusingyourPCor
smartdevice.
• EnsuretoenabletheDLNAsettingofyourdevicesrst.
• ASUSMediaStreamersupportsNFCfunction.Somefunctionsmayrequireyou
toinstallNFCEXPRESS2.Visitwww.asus.comformoreinformationaboutNFC
EXPRESS2.
• Thepublic-to-privatenetworkfunctionsfortheiOSsystemwillbeavailablefromMedia
StreamerV2.00.00orlaterversions.
• TheiOSsystemonlysupportphotoandvideostreamingforMediaStreamer.
System requirements
System requirements PC Smart device
OS
Windows
®
7/Windows
®
8.1/
Windows
®
10
Android4.0orhigherversions
iOS7orlaterversions
Utilities
ASUSHomeCloud ASUSMediaStreamer
