ASUS MAXIMUS VIII EXTREME
1-13
Chapter 1
DDR4 3466 (OC) MHz capability
DDR4 3500 (OC) MHz capability
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip
NO.
Timing Voltage
DIMM
socket
support
(Optional)
2 4
ADATA AX4U3466W4G16-DWZ 8GB (2 x 4GB) SS - - 16-17-17-36 1.35V •
ADATA AX4U3466W4G16-QWZ 16GB (4 x 4GB) SS - - 16-17-17-36 1.35V • •
APACER 78.BAGN1.4020B 8GB (2 x 4GB) SS - - 18-18-18-42 1.35V •
AVEXIR AVD4UZ134661704G-
2CIR/BZ1
8GB (2 x 4GB) SS - - 17-18-18-38 1.35V •
AVEXIR AVD4UZ134661704G-
4CIR/BZ1
16GB (4 x 4GB) SS - - 17-18-18-38 1.35V • •
CORSAIR CMD16GX4M4B3466C18 16GB (4 x 4GB) SS - - 18-19-19-38 1.35V • •
G.SKILL F4-3466C16Q-16GRRD 16GB (4 x 4GB) SS - - 16-18-18-38 1.35V • •
DDR4 3600 (OC) MHz capability
Vendors Part No. Size SS/DS
Chip
Brand
Chip
NO.
Timing Voltage
DIMM
socket
support
(Optional)
2 4
ADATA AX4U3600W4G17-DWZ 8GB (2 x 4GB) SS - - 17-18-18-38 1.35V •
ADATA AX4U3600W4G17-QWZ 16GB (4 x 4GB) SS - - 17-18-18-38 1.35V • •
APACER 78.BAGN2.4020B 8GB (2 x 4GB) SS - - 18-18-18-42 1.35V •
AVEXIR AVD4UZ136001804G-
2CIR/BZ1
8GB (2 x 4GB) SS - - 18-20-20-40 1.35V •
AVEXIR AVD4UZ136001804G-
4CIR/BZ1
16GB (4 x 4GB) SS - - 18-20-20-40 1.35V • •
CORSAIR CMD16GX4M4B3600C18 16GB (4 x 4GB) SS - - 18-19-19-38 1.35V • •
G.SKILL F4-3600C17-8GVK 8GB (2 x 4GB) SS - - 17-18-18-38 1.35V •
G.SKILL F4-3600C17-8GTZ 8GB (2 x 4GB) SS - - 17-18-18-38 1.35V •
G.SKILL F4-3600C17-16GVK 16GB (4 x 4GB) SS - - 17-18-18-38 1.35V • •
G.SKILL F4-3600C17-16CGTZ 16GB (4 x 4GB) SS - - 17-18-18-38 1.35V • •
Vendors Part No. Size SS/DS
Chip
Brand
Chip
NO.
Timing Voltage
DIMM
socket
support
(Optional)
2 4
G.SKILL F4-3500C17Q-16GRRD 16GB (4 x 4GB) SS - - 17-18-18-36 1.35V • •
