Asus rog maximus viii extreme [171/226] Chapter 4

ASUS MAXIMUS VIII EXTREME

4-21

Chapter 4

3. Fromthelistofavailablenetworks,selectanetworkthatyou

wanttoconnectto.

Somenetworksmayrequireyoutokeyinapassword.

Using the AP Mode

TheAPmodeallowsyoutosetyoursystemasanaccesspointforotherwireless-enabled

devices.

TouseAPmode,clickortapAP ModeontheWi-FiEnginemenu.

Click or tap to go back

to previous screen

Click or tap

to disable AP

mode

Click or tap

to enable AP

mode

Click or tap to select a network

Key in a network

name

Key in your

password

Key in your

password for

confirmation
