ASUS MAXIMUS VIII EXTREME

3-15

Chapter 3

CPU VRM Switching Frequency [Auto]

This item affects the VRM transient response speed and the component thermal

production. Select [Manual] to congure a higher frequency for a quicker transient

response speed.

Conguration options: [Auto] [Manual]

DO NOT remove the thermal module. The thermal conditions should be monitored.

The following item appears only when you set the CPU VRM Switching Frequency to

[Manual].

Fixed CPU VRM Switching Frequency (KHz) [500]

This item allows you to set a higher frequency for a quicker transient

response speed. Use the <+> or <-> to adjust the value. The values range

from 500 KHz to 800 KHz with an interval of 50 KHz.

DO NOT remove the thermal module when the manual mode is selected. The thermal

conditions should be monitored.

The following item appears only when the CPU VRM Switching Frequency is set to

[Auto].

VRM Spread Spectrum [Auto]

This item allows to enhance the system stability.

Conguration options: [Auto] [Disabled] [Enabled]

CPU Power Duty Control [T.Probe]

DIGI + VRM Duty Control adjusts the current of every VRM phase and the thermal

conditions of every phase component.

[T. Probe] Select to set the VRM thermal balance mode.

[Extreme] Select to set the VRM current balance mode.

DO NOT remove the thermal module. The thermal conditions should be monitored.

CPU Power Phase Control [Auto]

This item allows you to set the power phase control of the CPU.

Conguration options: [Auto] [Standard] [Optimized] [Extreme] [Power Phase

Response]

DO NOT remove the thermal module when setting this item to [Power Phase Response].

The thermal conditions should be monitored.

CPU Power Thermal Control [115]

Higher temperature provides a wider CPU power thermal range and extends the

overclocking tolerance to enlarge the overclocking potential.

Conguration options: [115] - [136]

DO NOT remove the thermal module. The thermal conditions should be monitored
