ZyWALL USG Support Notes
183
All contents copyright (c) 2010 ZyXEL Communications Corporation.
Step2. Go to Configuration > Network > Interface > Trunk, check the
SYSTEM_DEFAULT_WAN_TRUNK. All the external interfaces are included in it
now.
