Parts
333347K 105
* Purchase MZLP (118) and daughter board (112a) separately.
Available kits (purchase separately):
Internal Pattern Controller Components
% not shown
126
16T108 CABLE, ultrasonic, m12-4p, 1m
1 1 1 1 1 1
129
--- HARNESS, MZLP 2, awb
1 1
--- HARNESS, MZLP 2/3, awb
1 1
130
114958 STRAP, tie
4 4 4 4 4 4
131
--- SCREW, flange, serrated, 10-24 x 0.5
2 2 2 2 2 2
132
123967 KNOB, operator disconnect
1 1 1 1 1 1
135
16W035 CONNECTOR, jumper
1 1
136
--- HARNESS, MZLP 1, awb
1 1 1 1 1 1
137
--- BUSHING, cable
1 1 1
138
--- HARNESS, disc, awb
1 1 1 1 1 1
140
24V015 TRANSFORMER, assembly, 480v/240v
1 1 1
141
--- GROMMET, air fitting
1 1 1
142
113802 SCREW, hex hd, flanged, 3/8-16 x 5/8
3 3 3
143
24V816 MODULE, awb
1 1 1 1 1 1
144
114331 SCREW, mach, pnh, sems; 6-32 x 3/8
2 2 2 2 2 2
145
--- BRACKET, power supply
1 1 1
146
126453 POWER SUPPLY, 24v
1 1 1 1 1 1
147
--- HARNESS, power supply, awb
1 1 1 1 1 1
148
--- CABLE, board, samtec
1 1 1 1 1 1
Ref Part Description
Quantity
1 MZLP 2 MZLP 3 MZLP 1 MZLP 2 MZLP 3 MZLP
No Transformer 400/480 V Transformer
Kit Description Includes
24V528† Upgrade from 2
channel system to 4
channel system
113, 118, 121, 129, a ground-
ing wrist strap, and a software
upgrade token. See 4 Channel
Upgrade Kit, 24V528 on
page 126.
24V529✿ Upgrade from 4
channel system to 6
channel system
113, 118, 121, 129,134, 135,
grounding wrist strap, and a
software upgrade token. See 6
Channel Upgrade Kit, 24V529
on page 128.
24R040◆ RTD 125, 251, and 255. See Melter
and Pump Assembly on
page 107.
24V289 MZLP fuses Qty8-8Amp,250V Fuses
Qty2-25Amp,250V Fuses
24P176 Customer I/O Con-
nectors
2 connectors for connecting to
H1 and H2 on MZLP daughter
board. Use for PLC connec-
tion.
24X640† Add internal PC-8
to 2-channel or
4-channel systems.
181 (all items), 182, 183, 184,
185, 186, 189, 190, 192, 193.
See manual 334874.
17F172 Upgrade internal
PC-8 to PC-8e.
Key token to enable encoder
and 4 connectors for wiring.
See manual 334874.
Ref Part Description Qty
181+ 24X521 MODULE, GCA, Internal PC-8 1
181b+ 128176 FRAME, cable grip, 5-position 1
181c+ 128177 INSERT, rubber, cable grip, 4x6mm 1
181d+ --- PIN, .250 in 4
181e+ 128178 INSERT, rubber, cable grip, 4x3mm 4
181f+ --- PIN, .125 in 16
181g+ --- SCREW, #10-32 x .750 2
182+ 128180 POWER SUPPLY, 120 W 1
183+ 128443 BRACKET, power supply, PC-8
Internal
1
188+% --- TOOL, screwdriver 1
187+% 128340 FUSE, automotive, 4A, 32V, mini 1
189+ 116772 CONNECTOR, plug, 4-position 1
190+ 119162 CONNECTOR, plug, 6-position 2
192+ 128147 CONNECTOR, plug, 8-position 2
193+ 128117 CONNECTOR, plug, 12-position 1
