Models
333347K 5
Models
200-240 VAC, 350-415 VAC HM50 Standard Feed Models
* System comes with inter nal PC-8 pattern controller installed. To upgrade to PC-8e, order kit PN 17F712.
Complete
System Channels Voltage ˓ Type Description
Max
Amps
Melter
System
Feed
System
24T918
24Y114*
2
200-240
VAC
1˓ /PE
• 1-Phase
• 2 wire and PE
• 50/60 Hz
32A
24Y723 24N957
200-240
VAC ˂
3˓ /PE
• 3-Phase without Neutral
• 3 wire and PE
• 50/60 Hz
27A
300-415
VAC Y
3˓ / Neutral / PE
• 3-Phase with Neutral
• 350-415 VAC Line to Line
• 200-240 VAC Line to Neutral
• 3 wire, Neutral, and PE
• 50/60 Hz
16A
24T919
24Y115*
4
200-240
VAC
1˓ /PE
• 1-Phase
• 2 wire and PE
• 50/60 Hz
40A
24Y724 24N957
200-240
VAC ˂
3˓ /PE
• 3-Phase without Neutral
• 3 wire and PE
• 50/60 Hz
27A
300-415
VAC Y
3˓ / Neutral / PE
• 3-Phase with Neutral
• 350-415 VAC Line to Line
• 200-240 VAC Line to Neutral
• 3 wire, Neutral, and PE
• 50/60 Hz
16A
24T920 6
200-240
VAC
1˓ /PE
• 1-Phase
• 2 wire and PE
• 50/60 Hz
40A
24Y725 24N957
200-240
VAC ˂
3˓ /PE
• 3-Phase without Neutral
• 3 wire and PE
• 50/60 Hz
40A
300-415
VAC Y
3˓ / Neutral / PE
• 3-Phase with Neutral
• 350-415 VAC Line to Line
• 200-240 VAC Line to Neutral
• 3 wire, Neutral, and PE
• 50/60 Hz
30A
