![Graco InvisiPac HM50 [147/150] Mounting hole dimensions](/img/pdf.png)
Graco InvisiPac HM50 [147/150] Mounting hole dimensions
![Graco InvisiPac HM50 [147/150] Mounting hole dimensions](/views2/1193782/page147/bg93.png)
Technical Data
333347K 147
Mounting Hole Dimensions
ABC
HM25 10.3 in.
(261.6 mm)
3.3 in.
(83.8 mm)
3.3 in.
(83.8 mm)
HM50 11.1 in.
(281.9 mm)
4.0 in.
(101.6 mm)
4.0 in.
(101.6 mm)
WLD
WALL
Minimum distance from rear mounting
hole to wall: 7.0 in. (178 mm)
B
C
2.0 in.
(51 mm)
14.2 in.
(361 mm)
7.1 in. (180 mm)
A
5.3 in. (133 mm)
ABC
HM25 11.1 in.
(281.9 mm)
3.4 in.
(86.4 mm)
3.4 in.
(86.4 mm)
HM50 11.9 in.
(302.3 mm)
4.0 in.
(101.6 mm)
4.0 in.
(101.6 mm)
1.4 in.
C
5.3 in.
A
14.2 in. (361 mm)
B
7.1 in.
(134.6 mm)
(180 mm)
(35.6 mm)
