Maintenance
48 333347K
Filter Maintenance Guidelines*
* These recommendations are service level guidelines - actual service levels required in your factory will vary based
on environmental and operating conditions. High or low volume adhesive usage, as well as adhesives that contain a
powdered release agent or are otherwise dusty, will have an impact on the frequency of filter maintenance. To estab-
lish a preventative maintenance cycle tailored to your environment, Graco recommends inspecting filters every 4
weeks after installation and replacing when necessary. Document replacement intervals and use this as your preven-
tative maintenance schedule moving forward.
+ See appropriate applicator manual for part reference drawing.
#Standard on GS35 applicators.
%Optional upgrade to GM100 applicators.
Environmental Classification
Component Part Number Ref Clean Moderate Dusty
Pump Outlet Filter 24W595 236
Replace filter
every six
months
Replace filter
every four
months
Replace filter
every two
months
Applicator Manifold Filter 24P802 16 +
System Air Inlet Filter 24X967 64
Applicator Solenoid Mufflers 24P282#
24X037%
104+
NA
Feed funnel filter 24V506 705
Feed funnel inspection/cleanout N/A NA
