Parts
108 333347K
HM25 Melter and Pump, 17F830
HM50 Melter and Pump, 24V542
--- Not for sale.
Available kits (purchase separately):
Ref. Part Description Qty.
201 ---
BASE, melter, HM50
1
---
BASE, melter, HM50
1
202✖ ---
TANK, melter, HM50
1
---
TANK, melter, HM25
1
203• ---
MANIFOLD, outlet
1
204✖ ---
PLATE, mounting; HM50
1
---
PLATE, mounting; HM25
1
205 ❄ ---
HOUSING, fire rod; HM50
1
---
HOUSING, fire rod; HM25
1
206• 111317
RING, retaining, int.
3
207✖ 16W615
O-RING, fluoroelastomer;
(HM50 only)
1
126475
O-RING, fluoroelastomer;
(HM25 only)
1
208 24V522
BAND, heater; HM50 only
1
24R039
BAND, heater; HM25 only
1
209• ❄ ---
HEATER, rod,1500 watts; HM50
1
---
HEATER, rod, 500 watts; HM25
1
210 24R036
HEATER, rod,1000 watts; HM50
2
24R037
HEATER, rod,1500 watts; HM25
2
211✖ 128167
SCREW, cap,sh,5/16-18
7
213 24R369
SCREEN, wire
1
214• 112855
PACKING, o-ring
1
215
24T297
PLUG, o-ring boss
1
216ॠ---
SLEEVE, cylinder
1
217†‡• 108526
PACKING, o-ring, ptfe
2
218 24V558
MOTOR, double ended, air; see
page 110
1
219 ---
PLATE, pump adapter
1
220 ---
ROD, tie, 1.5 in. stroke
3
221• 192624
GUIDE, ball
1
222†◆• 239932
VALVE, piston
1
223◆• ---
ROD, piston
1
224†◆• 105444
BALL, (.31250)
1
225†◆• ---
SEAL, u-cup, piston
1
226†◆• ---
BEARING, piston
1
227†• 105445
BALL, (.5000)
1
228†• 192642
SEAT, carbide
1
229†• 107079
PACKING, o-ring
1
230• ---
HOUSING, foot valve
1
231†• 105802
O-RING
1
232†• 113944
PACKING, o-ring
1
233†• ---
BEARING, throat
1
234†‡• ---
SEAL, u-cup, throat
1
235• 193046
NUT, packing
1
236•
24P855
FILTER, assy, 100 mesh, welded
1
238 196762
PIN, straight
1
239 196750
SPRING, retaining
1
240 128190
SCREW, cap, sch; 5/16x1in.
3
242★• 117059
O-RING, fluoroelastomer
1
243★• ---
RETAINER, seat, dump valve
1
244★• 15Y627
PACKING, o-ring #2-116, ptfe
1
245★• ❄ ---
V
ALVE, relief
1
246• C19829
SCREW, cap, socket head; 5/16 x
2.5 in.
4
247• 15H304
FITTING, plug 9/16 sae
9
249 167002
INSULATOR, heat
10
251
✿•
126780
SWITCH, over temperature
1
252• ---
INSERT, helical
7
253✖ ---
PLATE, melter; HM25 only
1
---
PLATE, melter; HM25 only
1
254 ---
O-RING, -910
1
255
✿•
107388
SCREW, mach, pnh;
#4 x 3/8 in.
2
257 ---
BRACKET, shelf; HM50 only
1
---
BRACKET, shelf; HM25 only
1
258 ---
GROMMET, 1/4 ID
1
259 110298
SCREW, cap, sch,
1/4 x 7/8 in.;
HM50 only
4
115506
SCREW, mach, hex wash hd, 1/4 x
3 in.; HM25 only
4
268 115814
WASHER, flat, sst; HM50 only
4
269 128612
TUBE, cross over
1
270 103610
O-RING, 014
2
Kit Description Includes
24P852† Pump repair 217, 222, 224, 225, 226,
227, 228, 229, 231, 232,
233, 234, and seal
installation tool 15B661.
24P853‡ Cylinder 216, 217, 234, and seal
installation tool 15B661.
24P854◆ Pump rod 222, 223, 224, 225, 226
24P856★ Pressure relief valve 242, 243, 244, 245
24V508✖
24R031✖
Melter HM50 Melter
HM25
202, 204, 207, 211, 253,
and insulator (53). See
InvisiPac Systems
parts starting on
page 96 for insulator
(53) identification.
24R040
✿
Kit, RTD harness and
switch
125, 251, and 255. See
Electrical Enclosure,
Systems without Inter-
nal Pattern Controller
on page 102.
Ref. Part Description Qty.
