Accessories
333347K 115
Accessories
Special Tools
These special tools are designed to make system repairs as easy as possible while ensuring that parts do not get
damaged.
* Parts included in Cylinder Tools Kit 24R227 (pur-
chase separately).
** Parts included in Rod Tools Kit 24R228 (purchase
separately).
Part Purpose
1301* Remove Cylinder
1302* Install Cylinder - Female
1303* Install Cylinder - Male
Part Purpose
1304** Install Rod - Female
1305** Install Rod - Male
1306** Install Rod - Bullet
ti20983a
