Models
6 333347K
200-240 VAC, 350-415 VAC HM25 Models
* System comes with inter nal PC-8 pattern controller installed. To upgrade to PC-8e, order kit PN 17F712.
Complete
System Channels Voltage ˓ Type Description
Max
Amps
Melter
System
Feed
System
24V423
24Y102*
2
200-240
VAC
1˓ /PE
• 1-Phase
• 2 wire and PE
• 50/60 Hz
32A
24Y673 24N957
200-240
VAC ˂
3˓ /PE
• 3-Phase without Neutral
• 3 wire and PE
• 50/60 Hz
27A
300-415
VAC Y
3˓ / Neutral / PE
• 3-Phase with Neutral
• 350-415 VAC Line to Line
• 200-240 VAC Line to Neutral
• 3 wire, Neutral, and PE
• 50/60 Hz
16A
24V424
24Y103*
4
200-240
VAC
1˓ /PE
• 1-Phase
• 2 wire and PE
• 50/60 Hz
40A
24Y674 24N957
200-240
VAC ˂
3˓ /PE
• 3-Phase without Neutral
• 3 wire and PE
• 50/60 Hz
27A
300-415
VAC Y
3˓ / Neutral / PE
• 3-Phase with Neutral
• 350-415 VAC Line to Line
• 200-240 VAC Line to Neutral
• 3 wire, Neutral, and PE
• 50/60 Hz
16A
24V425 6
200-240
VAC
1˓ /PE
• 1-Phase
• 2 wire and PE
• 50/60 Hz
40A
24Y675 24N957
200-240
VAC ˂
3˓ /PE
• 3-Phase without Neutral
• 3 wire and PE
• 50/60 Hz
40A
300-415
VAC Y
3˓ / Neutral / PE
• 3-Phase with Neutral
• 350-415 VAC Line to Line
• 200-240 VAC Line to Neutral
• 3 wire, Neutral, and PE
• 50/60 Hz
30A
