3
3. Hardware Connection Description
In this chapter, we show how to connect the embedded computers to the network and to various devices.
The following topics are covered in this chapter:
Installing the TC-6000 Series Expansion Modules
Connecting Data Transmission Cables
TC-SP04-DB44-T Serial Port Module
TC-CP02-DB-T CAN Bus Module
TC-SW04-M12-4P-T/TC-SW04-M12-8P-T Switch Module
Installing Cellular Modules on the TC-DK10-T and TC-DK20-T
Installing a Cellular Module
Installing the SSD/HDD into the TC-SATA Module
