1
1. Introduction
TC-6000 expansion modules provide peripheral interfaces to TC-6000 series railway computers.
The following topics are covered in this chapter:
Overview
Package Checklist
Available Modules
TC-6000 Series Module Specifications
TC-DK10-T/TC-DK20-T Specifications
TC-SP04-DB44-T Specifications
TC-CP02-DB-T Specifications
TC-SW04-M12-4P-T/TC-SW04-M12-8P-T Specifications
TC-SATA-T Specifications (Available on Request)
