Autel AutoLink AL539B [21/92] Configure monitors
![Autel AutoLink AL539B [21/92] Configure monitors](/views2/1200931/page21/bg15.png)
19
Configure Monitors
From System Setup screen, use the UP/DOWN scroll button to select
Configure Monitors, and press the OK button. (Figure 3.5)
Figure 3.5
In this menu, you could configure the monitors required to test spark
ignition and compression ignition, the number of monitors to pass
diagnosis, and restore the default settings.
1) Spark IGN Required Monitors
From Configure Monitors screen, use the UP/DOWN scroll button to
select Spark IGN Required Monitors, and press the OK button.
The monitors for spark ignition engines list as below:
Spark IGN Required Monitors
√
MIS
√
EVAP
√
FUEL
√
AIR
√
CCM
√
O2S
√
CAT
√
HTR
√
HCAT
√
EGR
2) Compression IGN Required Monitors
Configure Monitors 1/4
Spark IGN Required Monitors
Compression IGN Required Monitors
Allowed INC Monitors ?
Reset Factory Default
