60
NOTE: If the On-Board Monitor Test failed, this monitor item
will be red color. Just by the text color you may easily find out
which system is at fault.
Figure 5.45
Figure 5.46
8) Press ESC button to return to the previous menus.
5.8 Component Test
The Component Test function allows initiating a leak test for the
vehicle's EVAP system. The scan tool itself does not perform the
leak test, but commands the vehicle's on-board computer to start
the test. Different vehicle manufacturers might have different
criteria and methods for stopping the test once it has been started.
Before starting the Component Test, refer to the vehicle service
manual for instructions to stop the test.
1) Use the UP/DOWN scroll button to select Component Test from
Diagnostic Menu and press the OK button. (Figure 5.4)
EVAP monitor
Phase 0 Initial tank vacuum an..
Phase 0 Initial tank vacuum 1
ID 00
MOD $10
TEST(in H2O) 0000 ?
MIN(in H2O) 7000
MAX(in H2O) 7200
STS Fail
