Autel AutoLink AL539B [61/92] Use the up down scroll button to select the desired monitor from on board mon test menu and press the ok button

Figure 5.42

 For CAN-equipped vehicles, test selections can be as below:

Figure 5.43

6) Use the UP/DOWN scroll button to select the desired monitor

from On-Board Mon. Test menu and press the OK button.

7) View test data on screen.

Figure 5.44

On-Board Mon. Test 1/31..

O2 Mon. B1S1

O2 Mon. B1S2

O2 Mon. B1S3

O2 Mon. B1S4

O2 Mon. B2S1

O2 Mon. B2S2

HO2S11 Voltage amplitu 1/36

ID 11

MOD $10

TEST(volts) 400 ?

MIN(volts) 1E1

MAX(volts) -----

STS OK

On-Board Mon. Test

The selected mode is

not supported

Press any key to con..
