Autel AutoLink AL539B [25/92] Tool self test
![Autel AutoLink AL539B [25/92] Tool self test](/views2/1200931/page25/bg19.png)
23
3) Press the OK button to save your selection and return to previous
menu.
Tool Self-test
The Tool Self-test function checks if the display, LED lamps and
keyboard are working properly.
A. Display test
The Display Test function checks if the LCD display is working
normally.
1) From System Setup screen, use the UP/DOWN scroll button to
select Tool Self-test, and press the OK button.
2) Select Display Test from Tool Self-test menu and press the OK
button to start test. (Figure 3.9 )
Figure 3.9
3) Look for missing spots in the red, green, blue, black and white
LCD display.
4) When completed, press the ESC button to exit.
B. Keyboard Test
The Keyboard Test function verifies if the keys are functioning
properly.
1) Use the UP/DOWN scroll button to select Keyboard Test from
the Tool Self-test menu, and then press the OK button.
Tool Self-test 1/3
Display Test
Keyboard Test
LED Test ?
