Autel AutoLink AL539B [38/92] Live data

Figure 5.9

 If the codes are not cleared, then an “Erase Failure. Turn

Key on with Engine off!‖ message appears.

Figure 5.10

4) Press any button to return to Diagnostic Menu.

5.3 Live Data

In this function, you can not only read the live data but also record

data for later review.

Viewing Data

The View Data function allows viewing of live or real time PID

data of vehicle’s computer module(s).

1) To view live data, use the UP/DOWN scroll button to select Live

Data from Diagnostic Menu and press the OK button. (Figure

5.4)

Erase Codes

Erase Failure.

Turn Key on with

Engine Off!

Press any key to con.

Erase Codes

Erase Done!

Press any key to con.
