62
4) Wait a few seconds or press any key to return to previous screen.
5.9 Viewing Vehicle Information
The Vehicle Info. function enables retrieval of Vehicle
Identification No. (VIN), Calibration ID Nos. (CINs),
Calibration Verification Nos. (CVNs) and In-use Performance
Tracking on 2000 and newer vehicles that support Mode 9.
1) Use UP/DOWN scroll button to select Vehicle Info. from the
Diagnostic Menu and press OK button. (Figure 5.4)
2) An advisory message comes up to remind you. Wait a few
seconds or press any key to continue.
Figure 5.50
3) Wait a few seconds while the scan tool reads vehicle information.
Figure 5.51
If the vehicle does not support this mode, a message shows on
the display warning that the mode is not supported.
Vehicle Info.
Reading info…
- Please Wait -
Vehicle Info.
Turn key on
with engine off !
Press any key to con.
