Autel AutoLink AL539B [44/92] Use the up down scroll button to select a memory location and press the ok button

Figure 5.21

 If data from previously tested vehicle is not erased, data from

current test will be stored in a temporary cache.

3) Use the UP/DOWN scroll button to select a memory location

and press the OK button.

Figure 5.22

 The asterisk (*) icon on the screen indicates that there is a

previous recording in the memory location.

 If you select a location marked with an asterisk (*) icon, a

message prompting to overwrite old recording displays.

Figure 5.23

…………….Select Memory 1/3..

Location #1 *

Location #2

Location #3 ?

…….……Pick Trigger Mode 1/2

Manual Trigger

DTC Trigger

Select Memory ...

A previous recording

exists! Do you want

to overwrite it?

YES NO
