There are two trigger modes used to record data:
A. Manual Trigger - allows user to press the OK button to start
recording.
B. DTC Trigger - automatically records PID data when a fault that
causes a DTC to set is detected by vehicle.
CAUTION: DO NOT try to drive and operate the scan tool at the
same time! Always have another person operate the scan tool
while driving.
To record live data, use the UP/DOWN scroll button to select
Record Data from Live Data menu and press the OK button. (Figure
5.12)
Recording Complete Data Set
1) To record complete set of live data, use the UP/DOWN scroll
button to select Complete Data Set from Record Data menu
and press the OK button.
Figure 5.20
2) Use the UP/DOWN scroll button to select a trigger mode and
press the OK button.
………………..Record Data 1/3..
Complete Data Set
Custom Data Set
Unit of Measure ?
