Autel AutoLink AL539B [65/92] Modules present

4) From Vehicle Info. Menu, use the UP/DOWN scroll button to

select an available item to view and press the OK button.

Figure 5.52

5) View retrieved vehicle information on screen.

Figure 5.53

6) Press the ESC button to return to previous menu.

5.10 Modules Present

The Modules Present function allows viewing of the module IDs

and communication protocols for OBD2 modules in the vehicle.

1) Use the UP/DOWN scroll button to select Modules Present

from Diagnostic Menu and press OK button. (Figure 5.4)

2) View modules present with their IDs and communication

protocols.

Vehicle Info. 3/3

Vehicle ID Number

Calibration ID

Cal. Verf. Number ?

Cal. Verf. Number

CVN1: BB BA A0 78
