52
Emissions Test can be performed. It is also suggested that the
vehicle be inspected/repaired before driving the vehicle further.
If the RED LED was obtained, there is a definite problem
present in the system(s). In these cases, you have the following
options:
Repair the vehicle yourself. If you are going to perform the
repairs yourself, proceed by reading the vehicle service
manual and following all its procedures and
recommendations.
Take the vehicle to a professional to have it serviced. The
problem(s) causing the red LED to light must be repaired
before the vehicle is ready for an Emissions Test.
Audio Tone Interpretation
The audio tone is configured according to the I/M Readiness Status.
This function is invaluable when performing diagnostics and driving
at the same time , or working in bright areas where LED illumination
alone is not sufficient.
Different audio tone with different LED light indicates different I/M
Readiness Status.
LED Light
Audio Tone
Beep Interval
Green LED
Two long beeps
5 seconds
Yellow LED
short, long, short beep
5 seconds
Red LED
Four short beeps
5 seconds
After you have read the information, press ESC to exit. The other
buttons are disabled to prevent misoperation.
B. Retrieve I/M Readiness status in typical way
