35
enhanced data. Further, the I/M Readiness Monitor Status for all
vehicle monitors is reset to Not Ready or Not Complete status. Do
not erase the codes before the system has been checked completely
by a technician.
NOTE: Erasing codes does not mean that trouble codes in ECU
have been eliminated completely. As long as there is fault with the
vehicle, the trouble codes keeps on presenting.
This function is performed with key on engine off (KOEO). Do
not start the engine.
1) Use the UP/DOWN scroll buttons to select Erase Codes from
Diagnostics Menu and press the OK button. (Figure 5.4)
2) A warning message comes up asking for your confirmation.
Figure 5.8
If you do not want to proceed with erasing codes, press ESC
button or use LEFT/RIGHT scroll button to select NO to
exit. A message of ―Command Cancelled!‖ show ups. Wait
a few seconds or press any key to return to Diagnostic
Menu.
3) Press the OK button to confirm.
If the codes are cleared successfully, an “Erase Done!”
confirmation message shows on the display.
Erase Codes
Erase trouble codes!
Are you sure?
YES NO
