Figure 5.40

4) After you select the vehicle manufacturer, the scan tool shows

the On-Board Monitors test results for specific monitored

systems.

Figure 5.41

5) From On-Board Mon. Test menu, use the UP/DOWN scroll

button to select a test to view and press the OK button. Or, use

the LEFT/RIGHT scroll button to view previous/next screen of

test items.

 If the vehicle under test does not support the mode, an

advisory message will be displayed on the screen.

Vehicle Manufacturer 1/28

BUICK

BMW

CADILLAC ?

CHRYSLER

FORD

On-Board Mon. Test 1/19

HO2S Monitor

Catalyst Monitor

EVAP Monitor
