- 12 -

NOTE If the camera cannot to your wireless network, you need to install

the camera in LAN and proceed with WLAN settings.

2.3 Applications of the Camera

The camera can be applied in multiple applications, including:

 Monitor local and remote places and objects via Internet or Intranet.

 Capture still images and video clips remotely.

 Upload images or send email messages with the still images attached.

The following diagram explains one of the typical applications for your

camera and provides a basic example for installing the camera.

Applications
