Trendnet TV-IP422W [53/111] General setting

- 52 -

NOTE Sliding the Threshold bar to the right will decrease the sensitivity

of motion detection; sliding the Threshold bar to the left will

increase the sensitivity of motion detection

4.9 Event Config

The Event Config menu contains five sub-menus that provide the

commands to configure event profiles.

Event Configuration >> General Setting

- Snapshot/Recording Subfolder: You can assign a descriptive

name for the subfolder to save the captured image/video files.

Otherwise, leave this option blank to use the default setting.
