Trendnet TV-IP422W [94/111] A specification

- 93 -

APPENDIX

A.1 Specification

 Image Sensor

Sensor 1/4” color CMOS

Resolution 640x480

 Video

Compression MPEG4/MJPEG

Video resolution VGA/QVGA/QQVGA; 30fps max.

 Audio

Input Built-in MIC

Output Headphone output jack (Mono)

Codec PCM/AMR (AMR is for 3GPP only)

 User Interface

LAN One RJ-45 port

Antenna One external antenna

Reset One Reset button

USB USB 1.1 port, with one unmount button;

Power distribution: 500mA Max.

Support FAT, FAT32 file system

GPIO 1 in/1 out connectors

Input: active high: 9~40V DC; dropout: 0V DC
