Trendnet TV-IP422W [7/111] Rear view
![Trendnet TV-IP422W [7/111] Rear view](/views2/1256814/page7/bg7.png)
- 6 -
Rear View
USB Unmount Button
is used to remove the
connected USB device
safely.
External Antenna
Connector connects
the external antenna.
GPIO Connectors
is used to connect the
external device.
Audio-out Connector
connects an external
active speaker.
Reset Button
will restart the camera when it
is pressed quickly; when it is
pressed and held for five
seconds, the camera will
resume the factory default
settings.
DC Power Connector
connects the AC
power adapter, in
order to supply power
to the camera.
Ethernet Cable Connector
connects the network
cable, which supports the
NWay protocol so that the
camera can detect the
network speed
automatically.
