Trendnet TV-IP422W [80/111] To link to the web page of the camera

- 79 -

To link to the Web page of the camera

Click SETTING > Camera List > Camera Configuration and then Link

web page to launch the Web browser that displays live view image and

Web Configuration of the selected camera.

Select a camera

Delete the camera
