- 74 -

- Video Viewing Window: This window displays the video view of

the selected camera, which can be divided into 4/9/16 windows

according to your selection in VIEW SELECTION panel.

- Camera List: This list displays the information of the connected

camera(s).

Camera List

Video Viewing

Window
