9
To select a parameter:
• press
or
To modify a parameter:
• press
• press
or in 15 s
• press
or do not operate 15 s.
To quit the procedure:
• press
and 4 s or do not operate 60 s.
Configuration parameters
LABEL MIN. MAS. U.M. DEF. WORKING SETPOINTS
SP r1 r2 °C/°F (1) 0 working setpoint
LABEL MIN. MAS. U.M. DEF. MEASURE INPUTS
CA1 -25 25 °C/°F (1) -1 cabinet probe offset
P0 0 1 - 1 kind of probe (0=PTC, 1=NTC)
P1 0 1 - 0 decimal point Celsius degree (for the quantity to show during the normal
operation) (1= YES)
P2 0 1 - 0 unit of measure temperature (2) (0=°C, 1=°F)
LABEL MIN. MAS. U.M. DEF. MAIN REGULATOR
r0 0.1 15 °C/°F (1) 3 working setpoint differential
r1 -99 r2 °C/°F (1) 0 minimum working setpoint
r2 r1 99 °C/°F (1) 10 maximum working setpoint
LABEL MIN. MAS. U.M. DEF. COMPRESSOR PROTECTIONS
C0 0 240 min 0 compressor delay since you turn on the instrument
C2 0 240 min 3 minimum time the compressor remainsturned off
LABEL MIN. MAS. U.M. DEF. DEFROST
d0 0 99 H 6 defrost interval; also look at d8 (5)
0=the defrost at intervals will never be activated
d3 0 99 min 20 defrost duration (0=the defrost will never be activated)
d4 0 1 - 0 defrost when you turn on the instrument (1=YES)
d5 0 99 min 0 defrost delay when you turn on the instrument (only if d4 = 1)
d6 0 1 - 1 temperature shown during the defrost
0=cabinet temperature1=if to the defrost activation the cabinet temperature is
below “working setpoint+ r0”, at most “working setpoint + r0”; if to the defrost
activation the cabinet temperature is above “working setpoint +r0”, at most the
cabinet temperature to the defrost activation (6)
(1) the unit of measure depends on parameter P2
(2) set the parameters related to the regulators appropriately after themodification of the parameter P2
(5) the modification of parameter d0 has effect since the end of the previous defrost interval or since the activation of a defrost by hand
(6) the display restores the normal operation as soon as the defrost ends and the cabinet temperature falls below the one that has locked the display (or if a
temperature alarm arises)
DEFROSTING
The defrosting of the refrigerating cabinets is totally automatic.
The air defrosting operation of the appliances occurs
automatically every 6 hours. The defrosting lasts 20 minutes.
A defrost cycle can be selected at any time by pressing button
“
”(see fig. b) for 5 seconds. The next automatic defrost
cycle will start 6 hours after pressing the button.
The appliance is supplied with an automatic evaporation
control for the condensed steam.
ALARMS AND SIGNALS
Alarms must be silenced by the “
” key.
Any alarm and signalling are visualized on the display:
The “
” led on indicates that the compressor is
activated.
The “
” led flashing indicates a delay in the compressor
activation.
The “
” led on indicates that the defrosting is running.
The “
” led flashing indicates a delay in the activation of
the defrosting.
“E0” flashing on the display can indicate one of the following
anomalies: improper type of cold room drill,
cold room drill or links defects, temperature out of the
temperature limit.
"E2" flashing on the display: corruption of the configuration
data in the memory; try to turn off the appliance and start it
again, if the alarm message disappears, change the heat
regulator.
Chamber temperature: if the display shows a correct value,
but the value is flashing, the temperature scanned by the
probe is behind the prefixed limits.
