1 General information
4
TCGB0068 rev.1 - 08/2012
1.3 Product guide
1.3.1 Classication of outdoor unit models
Unit type (Outdoor unit):
Position-separating hyphen (xed)
Compressor power (HP): 4, 5, 6
FS = SET-FREE system
V = Single phase unit (1~ 230V 50Hz)
N = R410A refrigerant
Y = Three phase unit (3N~ 400V 50Hz)
Series
E = Made in Europe
RAS – X FS (V) N (Y) 2 E
1.3.2 Classication of indoor unit models
Unit type (indoor unit): RCI, RCIM, RCD, RPC, RPI, RPIM, RPK, RPF, RPFI
Position-separating hyphen (xed)
Capacity (HP): 0.8, 1, 1.5, 2, 2.5, 3, 4, 5, 6
FS = SYSTEM FREE
N = R410A refrigerant
H = Hotel (RPK-(1.0/1.5) only)
2/3/4 = series
E = Made in Europe
M = Made in Malaysia
– = Made in Japan
i = Version up (RCI only)
DU = Drain Up (RPIM only)
XXX – X.X FS N (H) X (X) i (-DU)
