4 Capacities and
selection data
75
TCGB0068 rev.1 - 08/2012
4
To
Total power of combined indoor units (130%)
Ti
16 18 20 22 24
CAP IPT CAP IPT CAP IPT CAP IPT CAP IPT
-20
9.44 3.03 9.12 3.16 9.12 3.32 8.96 3.47 8.80 3.63
-17
9.73 3.06 9.50 3.19 9.41 3.35 9.25 3.50 9.18 3.66
-15
9.92 3.08 9.76 3.22 9.60 3.37 9.44 3.52 9.44 3.69
-13
10.30 3.11 10.14 3.24 9.98 3.40 9.82 3.55 9.82 3.71
-11
10.69 3.13 10.53 3.27 10.37 3.42 10.21 3.57 10.21 3.74
-10
10.88 3.16 10.72 3.30 10.56 3.45 10.40 3.60 10.40 3.76
-9
11.14 3.19 10.98 3.32 10.85 3.48 10.72 3.63 10.72 3.79
-7
11.65 3.21 11.49 3.35 11.42 3.50 11.36 3.65 11.36 3.82
-6
11.90 3.24 11.74 3.37 11.71 3.53 11.68 3.68 11.68 3.84
-5
12.16 3.27 12.00 3.40 12.00 3.55 12.00 3.70 12.00 3.87
-3
12.86 3.29 12.77 3.43 12.70 3.58 12.70 3.73 12.64 3.90
-1
13.57 3.32 13.54 3.45 13.41 3.61 13.41 3.76 13.28 3.92
0
13.92 3.34 13.92 3.48 13.76 3.63 13.76 3.78 13.60 3.95
1
14.30 3.37 14.30 3.50 14.14 3.66 14.11 3.81 13.95 3.97
3
15.07 3.40 15.07 3.53 14.91 3.69 14.82 3.84 14.66 4.00
5
15.84 3.42 15.84 3.56 15.68 3.71 15.52 3.86 15.36 4.03
6
16.32 3.45 16.16 3.58 16.00 3.74 15.84 3.89 15.68 4.05
7
16.68 3.47 16.48 3.61 16.36 3.76 16.20 3.91 16.00 4.08
9
17.40 3.50 17.12 3.64 17.08 3.79 16.92 3.94 16.64 4.10
10
17.76 3.53 17.44 3.66 17.44 3.82 17.28 3.97 16.96 4.13
11
17.89 3.55 17.57 3.69 17.54 3.84 17.38 3.99 17.06 4.16
14
18.27 3.58 17.95 3.71 17.82 3.87 17.66 4.02 17.34 4.18
15
18.40 3.61 18.08 3.74 17.92 3.89 17.76 4.04 17.44 4.21
RAS-6FSVN2E
To
Total power of combined indoor units (50%) Total power of combined indoor units (60%)
Ti Ti
16 18 20 22 24 16 18 20 22 24
CAP IPT CAP IPT CAP IPT CAP IPT CAP IPT CAP IPT CAP IPT CAP IPT CAP IPT CAP IPT
-20
5.13 1.91 4.95 1.99 4.95 2.09 4.86 2.18 4.86 2.29 6.16 2.26 5.94 2.36 5.94 2.48 5.83 2.59 5.83 2.72
-17
5.40 1.92 5.27 2.01 5.22 2.11 5.13 2.20 5.13 2.30 6.48 2.28 6.33 2.38 6.26 2.50 6.16 2.61 6.16 2.73
-15
5.58 1.94 5.49 2.02 5.40 2.12 5.31 2.22 5.31 2.32 6.70 2.30 6.59 2.40 6.48 2.52 6.37 2.63 6.37 2.75
-13
5.83 1.96 5.74 2.04 5.62 2.14 5.53 2.23 5.53 2.34 7.00 2.32 6.89 2.42 6.74 2.54 6.63 2.65 6.63 2.77
-11
6.08 1.97 5.99 2.06 5.83 2.15 5.74 2.25 5.74 2.35 7.30 2.34 7.19 2.44 7.00 2.56 6.89 2.67 6.89 2.79
-10
6.21 1.99 6.12 2.07 5.94 2.17 5.85 2.27 5.85 2.37 7.45 2.36 7.34 2.46 7.13 2.58 7.02 2.69 7.02 2.81
-9
6.32 2.01 6.25 2.09 6.10 2.19 6.03 2.28 6.03 2.39 7.58 2.38 7.50 2.48 7.32 2.60 7.24 2.71 7.24 2.83
-7
6.53 2.02 6.50 2.11 6.43 2.20 6.39 2.30 6.39 2.40 7.84 2.40 7.80 2.50 7.71 2.62 7.67 2.73 7.67 2.85
-6
6.64 2.04 6.62 2.12 6.59 2.22 6.57 2.31 6.57 2.42 7.97 2.42 7.95 2.52 7.91 2.64 7.88 2.75 7.88 2.87
-5
6.75 2.05 6.75 2.14 6.75 2.24 6.75 2.33 6.75 2.43 8.10 2.44 8.10 2.54 8.10 2.66 8.10 2.77 8.10 2.89
-3
7.18 2.07 7.18 2.16 7.15 2.25 7.15 2.35 7.11 2.45 8.62 2.46 8.62 2.56 8.58 2.68 8.58 2.79 8.53 2.91
-1
7.61 2.09 7.61 2.17 7.54 2.27 7.54 2.36 7.47 2.47 9.14 2.48 9.14 2.58 9.05 2.70 9.05 2.81 8.96 2.93
0
7.83 2.10 7.83 2.19 7.74 2.29 7.74 2.38 7.65 2.48 9.40 2.50 9.40 2.60 9.29 2.71 9.29 2.83 9.18 2.95
1
8.05 2.12 8.05 2.21 7.96 2.30 7.94 2.40 7.85 2.50 9.66 2.52 9.66 2.62 9.55 2.73 9.53 2.85 9.42 2.97
3
8.48 2.14 8.48 2.22 8.39 2.32 8.33 2.41 8.24 2.52 10.17 2.54 10.17 2.64 10.07 2.75 10.00 2.87 9.89 2.99
5
8.91 2.15 8.91 2.24 8.82 2.34 8.73 2.43 8.64 2.53 10.69 2.56 10.69 2.66 10.58 2.77 10.48 2.89 10.37 3.01
6
9.09 2.17 9.09 2.25 9.00 2.35 8.91 2.45 8.82 2.55 10.91 2.58 10.91 2.68 10.80 2.79 10.69 2.90 10.58 3.03
7
9.29 2.19 9.27 2.27 9.20 2.37 9.09 2.46 9.00 2.57 11.15 2.60 11.12 2.70 11.04 2.81 10.91 2.92 10.80 3.05
9
9.70 2.20 9.63 2.29 9.61 2.38 9.45 2.48 9.36 2.58 11.64 2.62 11.56 2.72 11.53 2.83 11.34 2.94 11.23 3.07
10
9.90 2.22 9.81 2.30 9.81 2.40 9.63 2.50 9.54 2.60 11.88 2.64 11.77 2.74 11.77 2.85 11.56 2.96 11.45 3.09
11
9.97 2.24 9.90 2.32 9.90 2.42 9.74 2.51 9.65 2.62 11.97 2.65 11.88 2.76 11.88 2.87 11.69 2.98 11.58 3.11
14
10.19 2.25 10.17 2.34 10.17 2.43 10.06 2.53 9.97 2.63 12.23 2.67 12.20 2.78 12.20 2.89 12.07 3.00 11.97 3.13
15
10.26 2.27 10.26 2.35 10.26 2.45 10.17 2.55 10.08 2.65 12.31 2.69 12.31 2.79 12.31 2.91 12.20 3.02 12.10 3.15
