10 Electrical wiring
121
TCGB0068 rev.1 - 08/2012
10
Electromagnetic compatibility
Following the Council Directive 2004/108/EC (89/336/EEC), relating to electromagnetic compatibility, next table indicates:
Maximum permissible system impedance Z
max
at the interface point of the user’s supply, in accordance with EN61000-3-11
MODEL Z
max
(Ω)
RAS-4FSVN2E 0.29
RAS-5FSVN2E 0.29
RAS-6FSVN2E 0.29
RAS-4FSNY2E —
RAS-5FSNY2E —
RAS-6FSNY2E —
Harmonics
Harmonics situation of each model regarding IEC 61000-3-2 and IEC 61000-3-12 is as follows:
MODELS SITUATION REGARDING
IEC 61000-3-2 and IEC 61000-3-12
MODEL Ssc “xx” (KVA)
Equipment complying with IEC 61000-3-2 (professional use)
RAS-4FSNY2E —
RAS-5FSNY2E —
RAS-6FSNY2E —
Equipment complying with IEC 61000-3-12
RAS-4FSVN2E —
RAS-5FSVN2E —
RAS-6FSVN2E —
